FEATURES

For mounting heights to 14′ (environmental separation) and 12′ (insect control).

The Berner Industrial Direct Drive 14 Air Curtain is durable with all welded construction and gray powder-coated exterior and mill aluminum inlet panel.

Used to save energy and keep temperatures stable and flying insects out when the doors are open.

  • AMCA certified ambient models only
  • Recommended for shipping and receiving doors, garage doors, cold storage doors, and baggage doors
  • Engineered to perform and built to last
  • Simple to install, operate, and maintain
  • Made in U.S.A.

Berner is a UL Listed panel shop, authorized to build UL listed Motor Control Panels.

Corro-Duty and Washdown Duty versions are available.

Available in single lengths from 3′ to 16′

AMBIENT

  • 15″ high x 18″ deep
  • 1 hp single-speed motor(s) — direct drive (optional: two-speed)
  • Gray powder-coated exterior with mill aluminum screen and access panels (optional: custom color or stainless)
  • Wall and top mounting
  • High-efficiency Pro-V Nozzle
  • AMCA certified

ELECTRIC HEAT

  • 15″ high x 18″ deep
  • 1 hp single-speed motor(s) — direct drive (optional: two-speed)
  • Gray powder-coated exterior with mill aluminum screen and access panels (optional: custom color or stainless)
  • Wall and top mounting
  • High efficiency Pro-V Nozzle
  • Patented venturi open helical element with point suspension
    • Thermal overload protection
    • Galvanized steel frame
  • Factory mounted heater control panel
  • Alternate KW available

STEAM / HOT WATER HEAT

  • 15″ high x 18″ deep
  • 1 hp single-speed motor(s) — direct drive (optional: two-speed)
  • Gray powder-coated exterior with mill aluminum screen and access panels (optional: custom color or stainless)
  • Wall and top mounting
  • High efficiency Pro-V Nozzle
Coil features:
  • Galvanized steel casing
  • 5/8″ copper tube with .035″ wall
  • Aluminum fins
  • Leak tested at 450 psi

INDIRECT GAS HEAT

Positive Indirect Gas

See mechanical drawings for dimensions.

  • 1 hp single-speed motor(s) — direct drive (optional: two-speed)
  • Gray powder-coated exterior with mill aluminum screen and access panels (optional: custom color or stainless)
  • Top mounting only
  • High efficiency Pro-V Nozzle
  • Factory mounted duct transition with bottom access panels
  • Field installed CSA Certified indirect gas heater(s):
    • Aluminized steel heat exchanger (Optional: Stainless)
    • Steel cabinet with beige finish
    • Spark ignited pilot
    • Power venter
    • Separate 120V power supply required (optional: transformer for single point connection)

Intelliswitch

Intelliswitch for Industrial Series Air Curtains

Optional

  • The Intelliswitch (digital controller) allows the user to program the air curtain to run for a set time in between door cycles, to operate on a schedule, and for air curtains with heat – to run until the thermostat set point is satisfied, and more..
  • Several pre-set programs to choose from or create one tailored to the application
Berner AIR and Intelliswitch Package

Optional

  • Includes BACnet-IP Support
  • Program, operate & monitor Industrial Air Curtains via Berner’s mobile app
  • Access reporting on energy & cost savings, door operations, and more

Accessories

This model requires a separate Activation Switch. All air curtains using control panels require an Activation Switch to be ordered with the panel. Models with Electric Heat include a factory mounted control panel.

Control Panels

Standard location: Factory installed on left hand end plate of air curtain.  Optional locations: Right hand end plate or remote mounted.

Single Phase Control Panels:

A single phase control panel is required when:

  • A time delay is used
  • 24 volt control is used
  • When motor quantities exceed: (1) 1 hp @ 120V or (2) 1 hp @ 208-240V

An activation switch must be selected along with the panel for activation of the air curtain.

Standard Control Panel Construction:NEMA 4/12 Enclosure, Motor Contactor (factory wired), Terminal Strip, Fusing (as required), Time Delay (as required).

Optional control panel enclosure constructions: Poly Fiberglass, Aluminum, Stainless Steel

Three Phase Control Panels:

All three phase power supplies require a three phase control panel and an activation switch.

Standard Control Panel Construction:NEMA 4/12 Enclosure, Motor Contactor (factory wired), Terminal Strip, Fusing (as required), and Time Delay or 120V Control Transformer (as required)

Optional control panel enclosure constructions: Poly Fiberglass, Aluminum, Stainless Steel

Location Specific Options

Corro-Duty and Washdown Duty versions are available.

Control Packages

Electric Heated Models Only

Models with Electric Heat include a factory mounted control panel.

Basic Control Package:

Recommended for openings where the door stays open for an extended period or does not have a lot of traffic.

  • Air curtain turns on when door is opened and shuts off when door is closed.
  • Consists of a door switch (roller, plunger, whisker arm, magnetic reed, or heavy duty magnetic reed style) and 24 volt control.
Deluxe Control Package:

Recommended for high traffic openings.

  • Air curtain turns on when door is opened, when the door closes, the unit remains on until set delay time expires.
  • Consists of a door switch (roller, plunger, whisker arm, magnetic reed, or heavy duty magnetic reed style), a time delay, and 24 volt control.

Electrical Accessories

  • Door Switches: roller, plunger, whisker arm, magnetic reed, heavy duty magnetic reed style
  • Hand/Off/Automatic switches
  • Disconnect Switch(es) – toggle disconnects based on number of power supplies required
  • Remote Thermostat & Locking Cover
  • Indirect Gas Heater Transformer – remote mounted

Mechanical Accessories

  • Wall support brackets
  • Extension brackets
  • Floor mounting brackets
  • Vertical tandem mounting bracket
  • ½” Washable filters
  • Nozzle extensions



Berner IntelliswitchTM

Digital Controller

  • Takes the place of Control Packages
  • Simplified pre-set programs
  • Single speed motor operation
  • LED clock display
  • Low voltage circuit for unit activation
  • Serial network connection available
  • External thermostat provision
  • Commercial grade components with operating range: 0° – 70°C or 32° – 158°F
  • RoHS compliant
  • Temperature probe (heated units only)
CONTROL PANEL is required when an Intelliswitch is used

Berner AIRTM Smart Controller & Berner App, includes BACnet

  • Requires IntelliswitchTM
  • Program, operate & monitor via smartphone / tablet
  • BACnet-IP support
  • Remote troubleshooting
  • Secure: best practices for cyber security protocols followed

NOTE: Requires on-site, secure wireless connection (provided by others).
